Hydronic Pump Stations to choose from

HPS "SERIES 900-IBC" Zone Control Stations  "NEW"

"PSS-IBC" - Primary/Secondary Stations - (IBC Boiler Applications)

click on image to enlarge





  • Consist of a pre-piped primary loop and the choice of up to 4 secondary zones
  • Left or right side supply and return to a condensing boiler
  • 27" x 25" x 8.5" box for wall mount
  • White Powder Coat Appliance Finish
  • Organic Acid Bath Polished Copper Piping
  • Electronic Relay Control Board allow each zone to be set, supplying either high or low temperature output from a condensing boiler
  • All field settings can be adjusted using jumpers
  • Priority with "Priority Safe Feature"
  • Pump Duty Cycle Timer Options
  • LED Indicator Lights
  • 3/4" union body secondary pumps-Grundfos UP15-42RUC7
  • 1" flange body Grundfos UPS 15-58FC Boiler Pump
  • Webstone "Isolator" Ball Valves
  • System Purge Valve
  • Return Zone Ball Valves
  • Integral Pump Flow Check Valves
  • Optional Air Vent FIP
